ZC-9D AC/HWDC Electromagnetic Yoke
Product Description
The light weight electromagnetic yoke is the ideal tool for detection of surface or sub-surface cracks and flaws in any ferromagnetic material. No other low cost, portable equipment offers such versatility in Magnetic Particle Inspection.
Fast and simple to operate, it is widely used with either dry or wet method fluorescent or non – fluorescent magnetic powders, in the testing of welds, automotive or railroad components, machine parts, steel and grey iron castings, forgings and in plan inspection, maintenance and repair.
Additional Information
| A.C. Magnetisation | ⦁ Creates a surface field which only detects surface cracks. ⦁ Particularly useful for inspecting thick and irregular sections for surface defects such as fatigue cracks. |
|---|---|
| D.C. (Pulsed) Magnetisation | Use of Half Wave D.C. Magnetisation creates a pulsing magnetic field with penetrates the work piece and detects surface and subsurface (Slightly) cracks. Pulsing improves particle mobility and sensitivity. Can be used for dry and even wet method. |
| Product Properties | ⦁ NDT Type: Fluorescent Magnetic Particle Testing |
| Application | Ideal Application: Infrequently used systems, Inspections where corrosion protection is vital, On high strength alloys, When maintaining particle concentration is critical, When water might pose an electrical hazard |
| Aprovals/Confirms | ⦁ ASTM E-I444 ⦁ ENISO 9934-1, ASTM E709 ⦁ ASME Boiler & Pressure Vessel. Section V, Art 7 |
